Home  >  Product&Solutions  >  7-inch digital industrial computer
7-inch digital industrial computer
  • 7-inch digital industrial computer
  • 7-inch digital industrial computer
  • 7-inch digital industrial computer
  • 7-inch digital industrial computer

7-inch digital industrial computer  Model: LY-TPCRK35

  • Model: LY-TPCRK35
1、 Industrial Automation and Intelligent Manufacturing Factory assembly line control: As an HMI human-machine interface driver control panel, it supports dual network ports to ensure stable communication, achieve equipment monitoring and command issuance. Lightweight machine vision: capable of performing tasks such as single camera barcode reading and basic positioning, suitable for quality inspection workstations. Industrial robot control: As the main control platform for multi axis motion controllers, it supports real-time collaboration and high-precision operation. 2、 Smart Retail and Commercial Equipment Self service terminal: used for self-service checkout machines and vending machine interaction interfaces, NPU accelerates product recognition and payment processes. Catering equipment control: integrated into commercial equipment such as coffee machines and barbecue machines, providing touch operation and status display. Digital signage management: Drive commercial display screens to achieve advertising playback and information push, supporting multi protocol communication. 3、 Smart Home and Building Management Home central control system: Centralize control of lighting, security, temperature control and other equipment, using Mali-G52 to accelerate graphical interactive interface. Intelligent access control/gate: supports facial recognition or QR code verification, with a wide temperature design suitable for outdoor environments. 4、 Energy and Power Monitoring Power concentrator: collect meter data through multiple RS485 interfaces to achieve edge computing and power consumption analysis. Substation monitoring terminal: Combined with the B-code timing interface, it completes millisecond level synchronization and cooperates with relay protection devices. 5、 Transportation and Logistics Vehicle mounted information terminal: used for logistics vehicle scheduling screen, bus stop announcement device, supporting multi screen display and GPS positioni

Tel:+86-18938679872

Inquiry
  • Product specifications


    systemCPURK3568
    menory2GB
    Solid state drives32GB
    operation systemAndiord 11
    displayLED screen7"LED screen
    resolution1024*600
    contrast800:1 (Typ.)
    brightness300 cd/m² (Typ.)
    Viewing angle85/85/85/85 (Typ.)(CR≥10
    Bare metal size388*237*40mm
    net weight1.6kg
    Screen ratio16:9/:344.16×193.59 mm (H×V)
    InernetWiFi2.4G
    EthernetYes
    BTOptional
    interfaceMini USBUSB *2
    RJ-451个
    Power jackDC 5.5/2.5
    audioStereoscopic HD
    COM portRS232
    Other inferfaces VGA/HDMI

    Touch pointsTen touches
    Other featuresWireless mouseYes
    Wireless keyboardYes
    horn2*3W
    OSD languageMultilingual OSD preratio in Chinese
    Special featuresACPI S3 power-saving mode is supported
    Support CPU fanless cooling
    Support for watchdog technology
    annexadapter12V/3A
    Wall-mounter metal fittingsMatching

    6面图 - 副本.jpg
