Home  >  Product&Solutions  >  32/43/50/55/65/75/85/98 inch vertical advertising machine
32/43/50/55/65/75/85/98 inch vertical advertising machine
  • 32/43/50/55/65/75/85/98 inch vertical advertising machine
  • 32/43/50/55/65/75/85/98 inch vertical advertising machine
  • 32/43/50/55/65/75/85/98 inch vertical advertising machine
  • 32/43/50/55/65/75/85/98 inch vertical advertising machine

32/43/50/55/65/75/85/98 inch vertical advertising machine  Model:LY-LSGGJ-32

  • Model:LY-LSGGJ-32
一、 Commercial retail field (main application scenarios) 1. Small and medium-sized shops (32-43 inches) Convenience store/specialty store: Display promotional information and new product recommendations at the counter (desktop or wall mounted). Restaurant/Coffee Shop: Menu and package promotions are displayed at the entrance to enhance customer decision-making efficiency. 2. Large commercial space (55-85 inches) Mall atrium/flagship store: 55-65 inch models play brand videos and event previews to shape a high-end image; Supermarket promotion area: Display discount list for 75-85 inch vertical machines, with touch screen for product inquiry during 618 shopping festival. 3. Interactive experience area (≥ 55 inches with touch) Support interactive functions such as virtual fitting and beauty experience to enhance consumer conversion (clothing, beauty stores). 二、 Transportation and Public Services Sector 1. Indoor hub (50-75 inches) Airports/train stations: 65-75 inch aircraft display schedule updates, security guidelines, and commercial advertisements; Subway station hall: 55 inch vertical screen provides route inquiry and exit navigation services. 2. Outdoor scenes (≥ 75 inch high brightness anti glare type) Bus stop/plaza: 85-98 inch models with strong light resistance display, broadcasting weather and public welfare information; Highway service area: Dual screen advertising machines (such as 55 inches) synchronously display information about restaurants and gas stations. 3. Government and Medical (43-65 inches) Hospital lobby: split screen display of department navigation, expert scheduling, and health education; Government Service Center: The 55 inch touch all-in-one machine provides service guides and form downloads. 三、 Cultural tourism hotels and educational institutions 1. Hotel Scene (32-55 inches) Lobby reception area: 43-50 inch models rotate hotel facilities and surrounding attractions; Elevator room/banquet hall: 32 inch vertic

Tel:+86-18938679872

Inquiry
  • Product specifications

    Liquid Crystal Parameters    Display and Brand55” LED (BOE)
    Display Ratio16:09
    Display Area1209*680
    Resolution1920*1080
    Dot Distance0.210×0.630 mm
    Horizontal Frequency30 - 80KHZ
    Vertical Frequency60/75HZ
    Number of colors167,700 true colors
    Lamp Life50000 hours
    Average Brightness350cd/m 2
    Contrast1400:01
    Viewing AngleUp and down 178° left and right 178°
    Input VoltageAC 110-220V(50HZ-60HZ)
    Power ManagementVESA DPMS compliant
    Power Consumption≤180W
    Operating Temperature0- 40 ℃
    Storage Temperature-10-50
    I/O interfaceUSB Interface4-way USB2.0
    Audio/Video OutputLeft and right channel outputs, built-in dual 4R/20W, 8R/10W amplifiers
    LAN Network Interface1 way RJ45
    power supplySupply VoltageDC12V/AC100-240V 50/60Hz (External)
    Standby Power (Energy Star)45W
    Touch ParametersTouch Frame BrandGODSPM
    Sensing TechnologyInfrared tube sensing, the number of tube pairs not less than 300 pairs
    Number of Touch PointsIR  points
    Sensing ObjectsFinger, pen and any other opaque objects
    Touch Accuracy<1.5mm (center area) <2.0mm (edge area)
    Resolution32767 X 32767
    Response timeSingle Point Mode:First Point (Click):8ms ,Continuous (Writing):3ms Multi-Point Mode:First Point (Click):8ms ,Continuous (Writing):8ms Mouse:First Point (Click):8ms ,Continuous (Writing):8ms
    Cursor speedSingle point: up to 300 points/second Multi point, mouse: 125 points/second
    LifespanGreater than 60,000,000 clicks
    Screen protection glass3mm optical glass, tempered
    Touch screen power supplyUSB power supply (4.6-5 volts, DC)
    Power ConsumptionLess than or equal to 1W
    Compatible SystemsCompatible with WIN7,WIN8 2-point operation and writing, support WIN7 gesture recognition
    PositioningCompliance with HID device standards, no need to locate, while supporting the management program to locate the correct. Optional 4-point or 5-point positioning
    Anti-Light Failure FunctionAnti-light degradation circuit, effectively prevent performance degradation due to long working hours.
    Power supplyMAGAMIT integrated power supply
    Storage Humidity5%~95
