Product Details

Compact HMI Touch Computers Baytrail Series

The PPC-1011 is a rugged front IP 65 rated 10.1", 11.6", 15.6", 17.3", 18.5" and 21.5" panel pc. Featuring Intel Baytrail J1800, J1900, N2807 embedded processor. The waterproof design protects the system from water and dust.
Low cost industrial panel PC for use in industrial settings, with mini PCIe expansion slots for WiFi, ideal for machine learning and AI. IP 65 stainless steel fanless panel pc support thorough cleaning.
The panel display using standard VESA mounting or Embedded solution or desktop solution. It meets the essential safety requirements set out in the applicable of CE. This system can be supplied with Windows 7, Windows 10 and Linux for option.

Model #	PPC-1511
Display	15.6
Touch	Capacitive Touch
Resolution	1920*1080
Brightness	300cd/m²
Bios	AMI BIOS
CPU	Intel Gemini Lake J4125/J4105/N4000
Chips	Intel® SOC
GPU	Intel® UHD Graphics 600
Internet	Realtek RTL8111H/RTL8111G
Audio	ALC269HD
RAM	DDR4 2133MHz/2400MHz
SSD	MINI-SATA
Function	WiFi、BT、4G、Watch Dog etc.
Up I/O	2*Antenar
	1*Button
	2USB 2COM(reserved)
Bottom I/O	1*LINE-OUT
	1*MIC-IN
	1*VGA
	1*HDMI
	1*USB3.0
	3*USB2.0
	1*LAN
	1*DC
	2*COM RS232 (reserved)
	1*M3 Ground
Power	Support 9~24V Wide Voltage
Speaker	2*4Ω 3W
Heat Sink	Fanless
Power Consumpiton	<17W
Install	Embedded, Mounting, Table
Dimension	379x238x42mm
Weight	<2.5kg
Color	Space Gray
Cabinet	Aluminium Alloy
OS	Windows 7 /Windows 10/Linux
